Hastelloy C22 DIN 2.4602 Rectangular Welded Pipes

Sunrise Steel Centre is a prestigious organization that is relatively engaged in offering a wide range of Hastelloy C22 Pipes and Tubes. We offer these UNS N06022 Pipes and Tubes in international and national quality of standards at cost-effective rates to our patrons. It is very similar to Hastelloy C-276 and is as well an excellent corrosion resistant and heat resistant alloy.

Hastelloy C22 DIN 2.4602 Rectangular Welded Pipes, Hastelloy C22 ERW Pipes Exporter, Hastelloy C22 EFW Tubing Leading Manufacturers.

ASTM B622 Hastelloy C22 Seamless Pipes, Hastelloy C22 ASME SB 619 Welded Tubes, Hastelloy C22 UNS N06022 Square Pipes Suppliers.

Hastelloy C22 ASME SB 622 Seamless Pipes Manufacturer, Hastelloy C22 ASME SB 574 Round Pipes, Hastelloy C22 Polished Pipes, ASME SB 626 Welded Pipes & Tubes, Hastelloy C22 Black Round Tubes Exporter.

It offers stress-corrosion cracking, crevice corrosion and resistance to pitting. They are being used in pollution control, chemical processing, pulp and paper production, waste treatment, marine seawater applications, etc. As a manufacturer, supplier, stockiest and exporter, we offer these Hastelloy Alloy C22 Pipes and Tubes in custom-made sizes and thicknesses as per the exact demands of our esteemed clients.

Hastelloy C22 Pipes & Tubing Equivalent Grades

STANDARD	WERKSTOFF NR.	UNS	JIS	BS	GOST	EN
Hastelloy C22	2.4602	N06022	NW 6022	–	–	NiCr21Mo14W

ASTM B622 / B619 / B626 / B575 / B574 Hastelloy C22 Pipe & Tubes Specification

Standard :ASTM, ASME B 622, B 619, B 775, B 516, B 626

Size :15NB TO 150 NB IN

Type :Seamless / ERW / Welded / Fabricated / LSAW Pipes

Form : Round, Square, Rectangular, Hydraulic Etc.

Length :Single Random, Double Ranidom & Cut Length

End :Plain End, Bevelled End, Treaded

Hastelloy C22 UNS N06022 Pipes & Tubes Chemical Composition

Element	Hastelloy C22
Ni	Bal
C	0.01 max
Mn	0.50 max
Co	2.5 max
S	0.02 max
Si	0.08 max
Cr	20 – 22.5
Mo	12.5 – 14.5
Fe	2 – 6
W	2.5 – 3.5
v	0.35 max
P	0.02 max

Hastelloy C22 Pipes & Tubing Mechanical & Physical Properties

Element	Hastelloy C22
Density	8.69 g/cm3
Melting Point	1399 °C (2550 °F)
Tensile Strength	Psi – 1,00,000 , MPa – 690
Yield Strength (0.2%Offset)	Psi – 45000 , MPa – 310
Elongation	45 %
Hardness (Brinell)	–
