Description
Titanium ASTM B348 Grade 2 Round Bar, Grade 2 Titanium Alloy Bright Bar, Ti Gr. 2 Rods Supplier in India.
Titanium UNS R50400 Bars, ASTM B348 Gr2 Titanium Square Bars Stockholder, Grade 2 Ti Cold Finished Bars, Titanium DIN 3.7035 Hot Rolled Bars Leading Manufacturers.
Titanium Alloy Grade 2 Hexagon Bar Dealers, Grade2 Titanium Forged Round Bars, B348 Titanium Alloy Gr2 Flat Bar, Titanium GR2 Black Bar, Ti Alloy Grade 2 Cold Drawn Bars Manufacturer, Stockist, Suppliers and Exporter
Titanium Grade 2 Rods lends itself to a multitude of products, from fasteners to jewelry. Meanwhile, the medical field time and again uses small-diameter round bar for dental appliances and body implantable fasteners. As a supplier, stockiest, exporter and manufacturer, we provide these round bars and rods in custom-built thicknesses and sizes according to exact requirements of our well-regarded patrons. We offer the same at economical prices to our consumers.
Titanium Alloy Grade 2 Round Bars Equivalent Grades
STANDARD | WERKSTOFF NR. | UNS |
Titanium Gr2 | 3.7035 | R50400 |
ASTM B348 Grade2 Titanium Alloy Round Bar Specification
Dimension : EN, DIN, JIS, ASTM, BS, ASME, AISI
Standard : ASTM B348 / ASME SB348
Size : Dia6.0-200mm x Length1000-6000mm
Tolerance : H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements
Form : Round, Square, Hex (A/F), Rectangle, Billet, Ingot, Forging Etc.
Finish : Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish
Form : Round, Square, Rectangular, Hydraulic Etc
Length : Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths
Titanium Grade 2 Round Bar Chemical Composition
Element | Titanium Gr2 |
C | 0.1 max |
Ti | 99.2 min |
N | 0.03 max |
Fe | 0.3 max |
H | 0.015 max |
O | 0.25 max |
ASTM B348 Grade 2 Titanium Bar & Rods Mechanical Properties
Element | Titanium Gr2 |
Density | 4.5 g/cm3 |
Melting Point | 1665 °C (3030 °F) |
Tensile Strength | Psi – 49900 , MPa – 344 |
Yield Strength (0.2%Offset) | Psi – 39900 , MPa – 275 |
Elongation | 20 % |
