A 106 GR B, A 106 GR C Carbon Steel Pipes & Tubes, ASTM A 106 Grade B / Grade C Seamless Tubing Suppliers
ASTM A 106 Grade B Rectangular Welded Pipes, ASTM A 106 ERW Pipes Exporter, ASTM A 106 Grade C EFW Tubing Leading Manufacturers.
ASTM A106 Welded Pipes & Tubes Manufacturer, ASTM A 106 GR. B Square Pipes stockist, ASTM A554 304 Polished Pipes, ASTM A 106 GR. B Round Tubes Exporter
ASTM A 106 Grade B Pipe & Tubes offers some of the finest features such as they are quite Sturdy construction in nature, along with having Dimensional accuracy and High durability. With respect to national and international quality of raw materials, we also offer these pipes and tubes in customized sizes and thicknesses as per specific demands by our esteemed clients at market leading prices.
ASTM A 106 Gr B/C Pipe & Tubes Specification
Specifications : A106 NPS 1/8 — 48 ANSI Schedules to 160
Pipes & Tubes : 1/2″ NB – 60″ NB
ERW Pipes & Tubes : 1/2″ NB – 24″ NB
SAW Pipes & Tubes : 16″ NB – 100″ NB
Thickness : SCH 40, SCH 80, SCH 160, SCH XS, SCH XXS, All Schedules
Type : Seamless / ERW / Welded / Fabricated / CDW
Form : Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes
Length : Single Random, Double Random & Required Length, Custom Size – 12 Meter lengths
End : Plain End, Beveled End, Treaded
ASTM A 106 Gr B/C Pipe & Tubes Chemical Composition
| Element | Composition, % | SS 304 |
| ASTM A106 Gr.B | ASTM A106 Gr.C | |
| C max A | 0.30 | 0.35 |
| Mn | 0.29-1.06 | 0.29-1.06 |
| P | 0.04 | 0.04 |
| S | 0.04 | 0.04 |
| Si | 0.10 | 0.10 |
| Cr | 0.40 | 0.40 |
| Cu | 0.40 | 0.40 |
| Mo | 0.15 | 0.15 |
| Nj | 0.40 | 0.40 |
| V | 0.08 | 0.08 |
ASTM A 106 Gr B/C Pipe & Tubes Mechanical Properties
| Grade | Tensile Strength (Mpa), Min. | Yield Strength (Mpa), Min. |
| B | 415 | 240 |
| C | 485 | 275 |
